Xigmatek AQUA Ultra Air Arctic
• Elegant and Easy Display Design
• Strong and Sophisticated Chassis Structure
• Crystal Clear 2 Tempered Glass Design
• Superior Airflow and Ventilation Design
• Easy SSD/HDD/PSU Installation
• Easy Cable Management
• Multiple Cooling Fan placement up to 10 x 12cm Fans
• Liquid Cooling Radiators Compatibility :
Bottom 360mm / Top:360mm / MB Panel:360mm
Top Visual Experience 2PCS
Tempered Glass Panel Design
Seamless Front & Left Panel with Dynamic ARGB LED Bar
Top Metal Panel with Removable Fan or AIO Liquid Cooler Bracket
Easily Mounting Panels
Removable Top Fan Rack
Bottom to Top Vertical
Airflow Design
High Airflow Anti-Dust Mesh Grill Bottom Panel Design,
Support 3PCS 120mm Cooling Fan for High Efficiency GPU & CPU Cooling.
Fan Support
Top: 120mm x3
MB: 120mm x3 or 140mm x3
Bottom: 120mm x3 or 140mm x3
Rear: 120mm x1
Reverse Fan Blade &
Traditional Fan Blade
Reverse Fan: Pre-installed on MB Panel & Bottom Side
Traditional Fan: Pre-installed on Rear Side
Radiator Support
Top:240/360
MB: 240/280/360
Bottom: 240/360
Rear: 120
Motherboard Support
up to E-ATX
Removable Motherboard
Extension Panel
CPU Cooler Clearance
up to 185mm
GPU Length Limitation
430mm
Support VGA Verticl
Installation
PSU Length Limitation
up to 220mm
Dual Chamber
A Well-Designed Chassis Enhances
PSU Cooling
Top Mount I/O Ports
• Power Button
• Reset Button
• LED Switch
• USB 2.0 x2
• USB 3.0 x2
• USB-C x1
• HD Audio Jack
Removable 2PCS
HDD/SDD Cages Included
Total Support 4PCS 3.5” HDD & 4PCS 2.5” SSD
*All Product Images Shown Are For Illustration Purpose Only.
